The Einhell TC-EH 500 cable winch enables heavy loads to be lifted comfortably and with minimum strain. Used without the guide roller the cable winch can lift loads up to 250kg to a height of up to 11.5m at the push of a button. Used with the guide roller the load is increased to 500kg and the lifting height is halved to 5.7 meters. The cable winch has a twelve meter twist-free cable (Ø 4.0 mm) for lifting. Comprehensive safety features include an emergency stop, thermostatic switch to protect the motor from overheating, automatic limit cut-out and safety catch on the load hook to prevent the load from dropping unintentionally. The automatic brake secures the load in every position. Two double clamps are provided for fastening the cable winch.
|Mains supply||230 V | 50 Hz|
|Max. power (S3 | S3%)||800 W | 20 %|
|Payload without return pulley||250 kg|
|Payload with return pulley||500 kg|
|Lifting height without return pulley||11.5 m|
|Lifting height with return pulley||5.7 m|
|Hoisting speed without return pulley||8 m/min|
|Hoisting speed with return pulley||4 m/min|
